SonarMite BTX Echosounder

Add to wishlistAdded to wishlistRemoved from wishlist 0

The SonarMite BTX Echosounder is a portable and compact underwater depth measurement device that uses sonar technology. It is manufactured by the British company Applied Acoustic Engineering Ltd. and is commonly used for hydrographic surveying, dredging, and environmental monitoring. The device is user-friendly and has Bluetooth connectivity for data transfer.


  • Transducer Frequency: 235KHz Active Transducer
  • Depths Range: 0.30m to 75.00m (Software limited)
  • Beam Spread: +/- 4 Degrees minimum
  • Accuracy: +/- 0.025m (RMS)
  • Sound Velocity Range: 1400 to 1600 m/sec
  • Data Output Range: 2 Hz
  • Ultrasonic Ping Rate: 3 to 6 Hz (Depth dependent)
  • Internal Power: 10.0v x 2.7AHr Interal Nickel Metal Hydride sealed battery (NiMh)
  • Power Consumption: 70ma to 120ma (temp dependent)
  • Usable Battery Life: 8Hrs to 12Hrs between charging
  • Stand-By Battery Life: 10000 Hours
  • Battery Charge: Smart switch mode charger for 90.250vac, 40.60Hz
  • Data Format (7 formats): RS232C 4800 baud 8 bit 1 stop bit No parity
  • Operating Temperature: 0 to 45 degrees Centigrade
  • Overall Dimensions: 100w x 220h x 450 (mm)
  • Weight: 0.75Kg
  • Provided with data collection software: compatible with windows (SonarW10)
  • Carrying Case: provided (IP08)
  • Mounting Pole: provided
  • Transducer Shoe Fitting: provided
  • Warranty: one year
